Timetable Editor

●Importing/exporting a timetable

Exporting a timetable

TheexportfunctionisusedtowriteoutatimetablesothatitcanbeusedwiththisproductonanotherPC.

Exportedtimetabledataincludesprogramsregisteredintimetables.

1. From the [File] menu, click [Export Timetable].

The[ExportTimetable]dialogboxwillappear.

2. Select the timetable folder containing the timetable.

3. From the “List of Timetable”, select a timetable, and

click [Export].

The[Selectthefoldertoexport]dialogboxwillappear.

4. Specify the directory where you want to save the le,

enter a “File name”, and click [Save].

The[ExportTimetable]dialogboxwillappear.

A screen like the one on the right will appear during

theexport.Click[Cancel]tocanceltheexport.

5. Click [OK].

Thetimetableexportisnowcomplete.

Creating a timetable
