Sharp ZQ-590 Specifiche Scaricare il pdf (Pagina 17)

To Do Mode

The To Do Mode is used to store your important To Do items with a

priority index.

Entry

You have to visit the NY Exhibition by December 10, 2005.

1. In the Main menu, tap

enter the To Do Mode.

2. In the To Do Mode, tap

“

to select

“New Entry” in the menu.

The To Do entry display will

appear.

3. Enter “12052005” at the date entry field. This will set up the Start

date of the event. When done, tap

Enter , or tap the next field.

4. In this field, set the end date of this event. Enter “12102005” for

December 10, 2005. When done, tap Enter to continue.

Note

The end date of the event must be later than the Start date.

5. Tap to set the priority number from 1 (High) to 5 (Low), then tap

Enter .

6. At the “To Do” description entry field, up to 482 alphanumeric

characters can be entered. Enter “Visit NY Exhibition”, then tap

to set and activate the entry.

Direct Search

Direct search can be done by either the Start date or the description

of an event.

1. In the Main menu, tap

to enter the To Do Mode.

2. In the ToDo Mode, tap

“

to select “Search Entry” in the menu.

The Search entry screen will appear.

3. Tap to select the “Date” or “To Do” checkbox.

If “Date” is selected, an entry area for date will appear. Enter the

date you wish to search. If “To Do” is selected, then a search string

can be entered in the field below.

4. When done entering, tap

to execute the search.
