SERVICE MANUAL

No. S97Q9LC37HT3U

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the

safety and performance of the set.

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

TopPage

LC-37HT3U/LC-37M43U

LCD COLOR TELEVISION

LC-37HT3U

LC-37M43U

MODELS

SUPPLEMENT

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-

inal condition and only parts identical to those specified should be used.

In this Service Manual, only parts in the LCD module are shown. For the other points, refer to the LC-37HT3U

(S97P6LC32HT3U) or LC-37M43U (S77L7LC32M43U) Service Manual and LC-32/37D42U (S06X9LC32D42U) Ser-

vice Manual.

OUTLINE

LC-37HT3U

LC-37M43U

1 2 3 4 5 6

SERVICE MANUALNo. S97Q9LC37HT3UParts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts wi

LC-37HT3U/LC-37M43U iLC-37HT3UService Manual OUTLINE AND ADJUSTMENT[1] OutlineIn this Service Manual, only parts in the LCD module are shown. For the

PARTS GUIDEParts marked with " " are important for maintaining the safety of the set. Be sure to replace theseparts with specified ones for

LC-37HT3U/LC-37M43U 2[1] LCD MODULE Assembly1920141115161716151819121310212230252431233030302927272727283245784266

LC-37HT3U/LC-37M43U3NO. PARTS CODEPRICE RANKNEW MARKPART DELIVERYDESCRIPTION[1] LCD MODULE Assembly1 R1LK370T3LZ6CZ EZ N J LCD Module Ass'y2 CANG
