Black plate (275,1)

2. Hold the end of the rubber and pull

until the tabs are free of the metal

support.

Metal support

Tab

3. Remove the metal stiffeners from the

blade rubber and install them in new

blades.

CAUTION

l

Don't bend or discard the stiffeners.

You need to use them again.

l

If the metal stiffeners are switched,

the blade's wiping efficiency could

be reduced.

So don't use the driver's side metal

stiffeners on the passenger's side, or

vice versa.

l

Be sure to reinstall the metal

stiffeners in the new blade rubber so

that the curve is the same as it was in

the old blade rubber.

4. Carefully insert the new blade rubber.

Then install the blade assembly in the

reverse order of removal.

NOTE

Install the blade so that the tabs are

toward the bottom of the wiper arm.

Maintenance and Care

Owner Maintenance

8-23

Mazdaspeed6_8U02-EC-05H_Edition1 Page275

Friday, July 15 2005 9:49 AM

Form No.8U02-EC-05H
