qReplacing Interior Light Bulbs

Overhead light/Map lights (Front)

1. Remove the screws.

2. Wrap a flat head screwdriver with a soft

cloth to prevent damage to the trim and

gently insert it in the overhead light as

shown in the figure, and then remove

the overhead light unit.

3. Turn the socket and bulb assembly

counterclockwise and remove it.

4. Disconnect the bulb from the socket.

5. Install the new bulb in the reverse order

of removal.

Overhead light/Map lights (Rear)

1. Wrap a flat head screwdriver with a soft

cloth to prevent damage to the trim and

gently insert it in the overhead light as

shown in the figure, and then remove

the overhead light unit.

2. Turn the socket and bulb assembly

counterclockwise and remove it.

3. Disconnect the bulb from the socket.

4. Install the new bulb in the reverse order

of removal.

8-34

Maintenance and Care
