CHECKING PACKED COMPONENTS

AND ACCESSORIES

Open the carton and check to ensure that the following components and accessories are included.

UNPACKING

Be sure to lift by the handles on both sides of the machine by two persons to unpack the machine and carry it to the

installation location.

Machine

Operation manual

and software CD-ROM

Power cord

Drum cartridge

(installed in machine)

TD cartridge

• If anything is not included or is damaged, contact your authorised service representative.

• Save the carton and packing materials. These can be re-used for transporting the machine, should it be

necessary.

Note

AL-1633_1644_EX.book 12 ページ２００３年１０月２３日　木曜日　午後８時２１分
