TROUBLESHOOTING AND MAINTENANCE
167
TD (Toner/Developer) cartridge and drum cartridge
1
Remove the TD (Toner/Developer) cartridge and drum cartridge
as explained in "TD (TONER/DEVELOPER) CARTRIDGE
REPLACEMENT" (p.161) and "DRUM CARTRIDGE
REPLACEMENT" (p.163).
2
Wipe the parts of the TD (Toner/Developer) cartridge and drum
cartridge shown below with a clean cloth.
Wipe only the parts that are indicated in the illustration.
3
Replace the TD (Toner/Developer) cartridge and drum cartridge
as explained in "TD (TONER/DEVELOPER) CARTRIDGE
REPLACEMENT" (p.161) and "DRUM CARTRIDGE
REPLACEMENT" (p.163).
If copies start becoming streaky or blotchy, the transfer charger may be dirty. Clean
the charger using the following procedure.
4
• Do not touch the surface of the drum (green portion).
Doing so may cause smudges on the copies.
• When cleaning the TD cartridge, do not tilt or shake it. Toner may spill
out and soil your clothes.
