MODELAR-F14SADDLE STITCH FINISHEROPERATION MANUAL•SADDLE STITCH FINISHER• PARTS OF THE SADDLESTITCH FINISHER • SPECIFICATIONS•FUNCTIONS OF THE SADDLE

8REPLACING THE STAPLE CARTRIDGE AND REMOVING STAPLE JAMSA message will appear in the display when the staple cartridge needs replacement or a staple j

9 Removing a staple jam1Press the detach button and separate the saddle stitch finisher from the machine.2Open the front cover.3Rotate roller rotating

1011Raise the lever on the front edge of the staple box.If the leading staple is bent, be sure to cut it off. If a bent staple is used for stapling, a

11REMOVING PAPER MISFEEDSWhen a paper misfeed occurs during copying, a message and picture will appear in the display of the operation panel as shown

12 Misfeed in the saddle stitch finisher1Press the detach button and separate the saddle stitch finisher from the machine.2Remove any misfed paper fro

1310Open the front cover.11Rotate roller rotating knob D in the direction of the arrow.12Remove any misfed paper from the saddle stitch tray.Remove th

14TROUBLESHOOTING (RELATED TO SADDLE STITCH FINISHER)If you experience difficulty with the saddle stitch finisher, check the following troubleshooting

15USING THE KEY OPERATOR PROGRAMSWhen the saddle stitch finisher is installed on the multifunction machine, the key operator programs indicated below

PRINTED IN JAPAN2004C DSC1TINSEXXXXQSZZPrinted on 100% post-consumer recycled paperAR-F14SHARP CORPORATIONCover4.fm 2 ページ ２００４年１月１５日　木曜日　午後６時３９分

The CE mark logo label is affixed on an equipment in case that the directives described in theabove sentence are applicable to the product. (This sent

1SADDLE STITCH FINISHERThe saddle stitch finisher features the offset function, which makes it easy to distinguish sets of output, and the saddle stit

2SPECIFICATIONS*1 Multiple punch modules cannot be installed together. Some models may not be available in some regions.*2 With AR-PN1B, two or three

3SuppliesThe following staple cartridge is required as a supply for the saddle stitch finisher:● AR-SC2 Staple Cartridge (approx. 5000 staples x 3)FUN

4 Punch function (only when a punch unit is installed)When an optional punch unit is installed on the saddle stitch finisher, holes can be punched in

5USING THE SADDLE STITCH FINISHER FUNCTIONS Using the saddle stitch finisher functions in copy modeTouch the [OUTPUT] key in the main screen of copy m

6 Using the saddle stitch finisher functions in printer modeTo use the staple function in printer mode, select "Properties" in the Print win

7The procedure for using the staple sort function is explained below.1Place the original (p.6).2Touch the [OUTPUT] key.3Touch the [STAPLE SORT] key.Wh
