MAKING COPIES
USING THE MANUAL FEED TRAY (special paper)
The manual feed tray is used to copy onto transparency film, labels,
tracing paper, and other special purpose papers. Up to 50 sheets of
standard copy paper can be set in the manual feed tray.
●
Automatic duplex copying will not work when a non-standard
sized paper is used. If a duplex copying mode is selected and a
non-standard sized paper is used from the manual feed tray, the
corresponding one-sided mode will be selected automatically
when the START key is pressed. (Automatic duplex copying can
be performed only when an optional duplex module is installed.)
1
Place the original face down on the document glass
and close the document cover.
2
Open the manual feed tray.
3
Set the manual feed tray guides to the width of the copy
paper.
●
Be sure to extend the tray when feeding B4 or A3 (8-1/2" x 14"
or 11" x 17") sized paper.
4
Insert the copy paper all the way into the manual feed
tray.
●
Transparency film, labels, tracing paper, and other special
purpose papers must be fed individually.
●
Up to 50 sheets of standard copy paper measuring from A5 to
A3 (5-1/2" x 8-1/2" to 11" x 17") can be loaded into the manual
feed tray.
●
For automatic two-sided copying of A5 paper (when an optional
duplex module is installed), position the side guides against the
copy paper’s longest side.
●
A6 size paper must be fed narrow side into the feed slot and
must be fed individually.
●
When adding paper, first remove remaining paper, combine it
with the paper to be added and then reload as a single stack.
5
Use the TRAY SELECT key to select the manual feed
tray.
6
Leave the copy quantity at 0 if using special papers.
Enter the number of copies if using standard copy
paper.
7
Press the START key.
Using the manual feed tray (special paper)
LIGHT DARK
TRAY SELECT
A4
B4
B4
1.
A3
2.
START
