7-11
CHAPTER7
6
Insert the new staple cartridge into the box until it clicks
in place.
●
Insert the new cartridge by aligning the arrows on the cartridge
with those on the box. Check that the cartridge locks in place by
pulling it slightly.
●
The cartridge holds 5,000 staples.
7
Remove the rear paper and tape from the cartridge.
●
Pull them straight. If they are pulled obliquely, the tape may be
torn.
8
Insert the staple box to the stapler unit until it clicks into
place.
9
Return the stapler unit to face down.
10
Push the finisher toward the copier and latch it in place.
OPTIONAL EQUIPMENT
Finisher (AR-FN1N)
FINISHER (AR-FN1N)
