12
BEFORE USING THE FAX FUNCTION
FAX MODE (BASE SCREEN)
The base screen of fax mode is displayed by pressing the [FAX] key when the print mode, copy mode, or scan mode
screen appears.
The base screen of fax mode
(1) Message display
Messages appear here to indicate the current
status of the machine.
An icon ( ) appears to the right side when a
confidential fax has been received.
(2) Date and time display
This shows the date and time.
(3) Transmission mode display (page 25)
There are three transmission modes: memory
transmission, direct transmission, and manual
transmission. This shows the currently selected
transmission mode.
(4) Exposure display (page 17)
This shows the exposure for scanning the original
that has been selected with the [RESOLUTION]
key.
(5) Resolution display (page 17)
This shows the resolution for scanning the
original that has been selected with the
[RESOLUTION] key.
(6) Free memory display
This shows the percentage of fax memory that is
free.
(7) Reception mode display (page 63)
There are two modes for receiving faxes:
automatic reception and manual reception. This
shows the currently selected reception mode.
(8) Original display (page 16)
This displays an icon to indicate the original
scanning mode when an original has been
placed.
: One-sided original scanning in the SPF.
: Document glass
: Two-sided original scanning in the RSPF.
This also shows the size of the placed original.
Stand-by. 96%
MAY 10 MON 10:25 AM
MEMORY AUTO
CONT 8 x11R
STANDARD
AUTO
(2)
(3)
(4)
(5)
(1)
(7)
(8)
(6)
1
2
The following functions operate even when copy mode is selected:
• Automatic reception (including F-code confidential reception)
• Timer Transmission
• Memory polled function
• Transmission of stored memory transmission jobs
• Voice calls (voice calls can be answered but not placed).
• Remote reception
• Manual reception
• Relay station function for F-code relay broadcast transmission
Note
