Connections

1. Installation

Connecting the Handset

Connect the handset as shown and place it on the handset rest.

♦

The ends of the handset cord are identical, so they will go into

either socket.

Use the handset to

make ordinary phone

calls, or to transmit and

receive faxes manually.

Make sure the handset

cord goes into the socket

marked with a handset

symbol on the side of the

machine!

all-Fo50A.book Page 15 Friday, October 1, 1999 5:32 PM
