6-5

Push the memory module into the slot firmly at an angle of about 20 degrees.

Gently push the memory module down until you hear a clicking sound

Projected Part

Notched part

Replace the RAM board slot cover. Make sure two

▼

marks face each other;

then, slide the cover to the left.
