Sharp VL-E40S Informazioni Techniche Pagina 102
- Pagina / 158
- Indice
- SEGNALIBRI
Valutato. / 5. Basato su recensioni clienti
2030Integratedcamera
Foraccess,removetheseFRUs,inorder:
•“1010Batterypack”onpage58
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
•“1150LCDunit”onpage79
•“2010LCDfrontbezel”onpage94
Removalstepsoftheintegratedcamera
1
2
Wheninstalling:Makesurethattheconnectorisattachedrmly.
2040Hinges,LCDpanel,LCDcable,andLCDrearcoverassembly
Foraccess,removetheseFRUs,inorder:
•“1010Batterypack”onpage58
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
•“1150LCDunit”onpage79
•“2010LCDfrontbezel”onpage94
96HardwareMaintenanceManual
