28
Specifications
Relevant signal timings (digital)
- Recommended resolution is 1024 x 768.
- All are compliant only with non-interlaced.
- A computer with an output terminal conforming to
DVI (DVI-D 24 pin or DVI-I 29 pin) and with XGA
output capability can be connected here.
(Depending on the type of computer to be
connected, the display may not work correctly.)
- If the monitor is receiving timing signals that are
not compatible, [OUT OF TIMING] will appear.
Follow your computer's instruction manual to set
the timing so that it is compatible with the
monitor.
- If the monitor is not receiving any signal (synch
signal), [NO SIGNAL] will appear.
US text
Screen resolution
Hsync Vsync
Dot
frequency
VESA
Relevant signal timings (analog)
- Recommended resolution is 1024 x 768.
- All are compliant only with non-interlaced.
- Frequencies for Power Macintosh are reference
values. To connect, another adapter
(commercially available) may be required.
- If the monitor is receiving timing signals that are
not compatible, [OUT OF TIMING] will appear.
Follow your computer's instruction manual to set
the timing so that it is compatible with the
monitor.
- If the monitor is not receiving any signal (synch
signal), [NO SIGNAL] will appear.
VESA
US text
Power
Macintosh
series
Hsync Vsync
Dot
frequency
Screen resolution
