Chapter 3 Configuring the Scan Settings
Appendix
Glossary
Introduction
Index
Contents
TOP
60
How to Load
Documents
Configuring the
Scan Settings
Various Ways to
Scan
Daily Care
Troubleshooting
Operational
Settings
Replacing the
Consumables
Scanner
Overview
How to Use the
Operator Panel
z When changing the scan settings in an ISIS application
(performing a scan after closing this dialog box)
[Scan] button
Performs a scan with the current scan settings.
[Close] button
Saves the current scan settings and closes the dialog box
(scanning is cancelled).
[OK] button
Saves the current scan settings and closes the dialog box.
[Reset] button
Cancels the changes made on the dialog box and restores the
original settings.
[Cancel] button
Discards the changes made on the dialog box and closes the
dialog box.
[Preview] button
Performs a test-scan with the current settings and displays the
result in Preview.
When scanning from ADF, the first document (only front side
when document is double-sided) is scanned.
