5-30 P/N 13999-002 Info Manual
Section 5 Cirrus Design
Performance Data SR20
Figure 5-17
Range / Endurance Profile
65% POWER Mixture = Best Power
Press
Alt
FT
Climb
Fuel
Gal
Fuel
Remaining
For Cruise
Gal
Airspeed
KTAS
Fuel
Flow
GPH
Endurance
Hours
Range
NM
Specific
Range
Nm/Gal
0 0.0 46.3 137 10.5 4.4 608 13.0
2000 0.6 45.7 139 10.5 4.4 620 13.1
4000 1.3 45.0 141 10.5 4.4 628 13.2
6000 2.0 44.3 143 10.5 4.4 635 13.2
8000 2.9 43.4 145 10.5 4.4 645 13.3
10000 3.8 42.5 147 10.5 4.4 654 13.3
12000 5.0 41.3 150 10.5 4.4 666 13.4
14000 6.8 39.5
55% POWER Mixture = Best Economy
Press
Alt
FT
Climb
Fuel
Gal
Fuel
Remaining
For Cruise
Gal
Airspeed
KTAS
Fuel
Flow
GPH
Endurance
Hours
Range
NM
Specific
Range
Nm/Gal
0 0.0 46.3 127 8.4 5.5 708 15.2
2000 0.6 45.7 130 8.4 5.5 726 15.5
4000 1.3 45.0 131 8.4 5.5 731 15.4
6000 2.0 44.3 134 8.4 5.5 745 15.6
8000 2.9 43.4 136 8.4 5.5 755 15.7
10000 3.8 42.5 139 8.4 5.4 768 15.9
12000 5.0 41.3 141 8.4 5.4 776 15.9
14000 6.8 39.5 144 8.4 5.4 785 16.0
Sheet 2 of 2
September 2011
