Powering off the Cartridge Subsystem
3-8 Tenth Edition 9871
9490 and SD-3 Cartridge Drive
CAUTION:
LOSS OF DATA. Pressing the Unit Emergency switch starts an
uncontrolled power off and might cause a loss of data. USE THE UNIT
EMERGENCY SWITCH ONLY IN AN EMERGENCY.
To power off a cartridge drive in an emergency:
1. Locate the
Unit Emergency switch on the power control panel at the rear of
the cartridge drive.
2. Lift the plastic cover to allow access to the switch.
3. Press the red
Unit Emergency switch, shown in Figure 3-5.
4. Notify Customer Support Services to dispatch a service representative to
restore power to the subsystem as described in Chapter 4, “Obtaining
Support.”
Figure 3-5. Unit Emergency Switch
C
4
0899
POWER
UNIT EMERGENCY
POWER
HOLD
INDICATOR
OI
