4-16
USING THE EDITING FUNCTIONS
The magazine sort mode allows 1-sided originals to be copied and sorted so that they can be folded and
bound along a center line like typical magazines or booklets.
Example of copying a 12-page document
• If used in combination with the optional saddle stitch finisher (AR-F12), copies can be automatically
folded in half and stapled along their center line. LD, LT-R, A3, A4-R, B4 are available.
* Magazine Sort can be accessed from two locations. For the mode operated from the BASIC menu
when the finisher (optional) is installed, see page 6-6.
9. MAGAZINE SORT (FROM THE EDITING MENU)
1
Place paper in the drawer(s). Page 2-4
2
Select the paper type.
For drawer feeding Page 3-2 (step 3)
For bypass feeding Page 5-9 (step 4)
3
Place the original(s). Page 2-9
- When placing them in the reversing automatic document
feeder, set them by referring to the order of pages in the
illustrations above.
- When placing them on the glass, place the first page of the
originals first.
4
Press the EDIT key to enter the edit menu, and
press the MAGAZINE SORT key.
- If the desired function keys are not displayed, press the Next
or Pre key to change the menu screen.
12
3
2
1
112
94
76
76
12
3
2
1
