CHECKING PACKED COMPONENTS AND

ACCESSORIES

Open the carton and check if the following components and accessories are

included.

If anything is missing or damaged, contact your authorized service representative.

PREPARING THE MACHINE FOR INSTALLATION

Be sure to hold the handles on both

sides of the machine to unpack the

machine and carry it to the installation

location.

If the machine does not function properly during setup or use, or if a

function cannot be used, see "TROUBLESHOOTING AND

MAINTENANCE" (p.69).

Note

Cautions leaflet

CD-ROM

Telephone line cord

(AL-2060 only)

Drum cartridge

(installed in unit)

TD cartrid

Power cord
