PREPARATIONS

Remove all pieces of tape shown in the illustration below and

then open the RSPF and remove the protective materials. Take

out the bag containing the TD cartridge.

Release the scan head locking switch.

The scan head locking switch is under the document glass.

If the switch is locked ( ), the machine will not operate. Unlock the switch

( ) as shown below.

To lock the scan head locking switch, hold up the catch in illustration and

turn the center knob counter-clockwise 90 degrees until you hear a click.

Lock Unlock

Grasp here and turn in

the direction of the arrow.
