7-5

Slide rail

Adding Paper to the External LCF (Large Capacity Feeder)(optional)

Pull the external LCF out carefully until it comes to

a stop.

- Be careful not to touch the drawer slide rail.

Place the paper on the elevator tray.

- Place the paper face up.

- Maximum number of sheets that can be set Page 2-4

- Fan the paper well, then place it on the elevator tray, align-

ing it on the rear guide tray.

- Set the paper so that it does not protrude beyond the line of

indication shown on the rear guide plate.

- Do not use creased, folded, wrinkled or damp sheets of

paper.

Close the cover of the external LCF.

- Close the cover completely. The elevator tray automatically

moves up to the paper feeding position.

MAX

Be careful not to let your fingers be caught when closing

the drawer.
