41
PERIPHERAL DEVICES AND SUPPLIES
3
REVERSING SINGLE PASS FEEDER / SINGLE PASS
FEEDER
For the names of the parts of the RSPF / SPF, see "PART NAMES AND FUNCTIONS" (page 12).
Specifications
*1 Two-sided scanning is not possible.
*2 During one-sided copying
250-SHEET PAPER FEED UNIT / 2 X 250-SHEET
PAPER FEED UNIT
• The 250-sheet paper feed unit provides a tray that can hold 250 sheets (20 lbs. (80 g/m
2
)) of plain paper.
• The 2 x 250-sheet paper feed unit provides two trays that can each hold 250 sheets (20 lbs. (80 g/m
2
)) of plain
paper.
Loading paper in the 250-sheet paper feed unit / 2 x 250-sheet
paper feed unit
The method of loading paper is the same as for the paper trays on the machine (see the explanation on page 18).
Specifications
Model AR-SP6N AR-RP6N
Acceptable
originals
Weight 15 lbs. to 24 lbs. (56 g/m
2
to 90 g/m
2
)
Original sizes 5-1/2" x 8-1/2" to 11" x 17" (A5 to A3)
Capacity
Up to 40 sheets (thickness 11/64" (4 mm) or less) (for 8-1/2" x 14" (B4) or larger
originals, up to 30 sheets)
Detectable original sizes
5-1/2" x 8-1/2"*
1
, 8-1/2" x 11", 8-1/2" x 11"R, 8-1/2" x 14", 11" x 17"
(A5, B5, B5R, A4, A4R, B4, A3)
Original exchange speed*
2
When installed on AR-M162: 16 pages/min.
When installed on AR-M207: 20 pages/min.
Weight 11.1 lbs. (5.0 kg) 12.0 lbs. (5.4 kg)
Dimensions
22-61/64" (W) x 17-9/64" (D) x 5-1/4" (H) (583 mm (W) x 435 mm (D) x 133 mm (H))
If you change the size of paper loaded in the tray, you must change the tray's paper size setting. Change the
setting as explained in "CHANGING THE PAPER SIZE SETTING OF A TRAY" on page 21.
Model AR-D24 AR-D25
Paper size 8-1/2" x 11"R, 8-1/2" x 11, 8-1/2" x 13", 8-1/2" x 14", 11" x 17", B5, B5R, A4, A4R, B4, A3
Paper
capacity
Approximately 250 sheets (20 lbs. (80 g/m
2
)) x
1 tray
Approximately 250 sheets (20 lbs. (80 g/m
2
)) x
2 trays
Paper weight 15 lbs. to 24 lbs. (56 g/m
2
to 90 g/m
2
)
Power supply Supplied from the machine
Dimensions
23-15/64" (W) x 16-27/64" (D) x 3-15/32" (H)
(
590 mm (W) x 471 mm (D) x 88 mm (H))
23-15/64" (W) x 16-27/64" (D) x 6-27/32" (H)
(
590 mm (W) x 471 mm (D) x 173.5 mm (H))
Weight 11.0 lbs. (5.0 kg) 22.0 lbs. (10.0 kg)
Note
