8-14 User’s Guide

Offset Catch Tray

Accessories

5. While holding up the duplex module, remove the right and left tabs of the duplex module

from the holes at the back of the printer.

6. Push in the cover and connector cover, which were removed during installation of the

duplex module, until it clicks into the back of the printer.

Offset Catch Tray

Install this tray to the printer to enable print jobs to be offset. Maximum capacity is 500 sheets.
