MISFEED REMOVAL
2-21
2
Misfeed in the stand/1 x 500 sheet paper drawer
1
Open the upper and lower side covers.
Push the lever upward
and gently open the
cover.
2
Remove the misfed paper.
Be careful not to tear the
misfed paper during
removal.
3
If misfed paper is not found in step 2, pull
out paper tray 1 and remove the misfed
paper.
Be careful not to tear the
misfed paper during
removal.
4
Gently push the paper tray into the
machine.
Push the tray firmly all the way into the machine.
5
Gently close the upper and lower side
covers.
After closing, confirm
that the misfeed
message has been
cleared and the normal
display appears.
Misfeed in the stand/3 x 500 sheet paper drawer
To remove a misfeed in the upper, middle, or lower tray, follow steps 1 through 5 above of "Misfeed in the stand/1
x 500 sheet paper drawer".
NOTE
Paper misfed from a paper tray may be extending out of the tray into the right side cover area. In this case if the
tray is drawn out of the machine, the paper may become torn and difficult to remove. To prevent this from
happening, always open the right side cover first and remove the misfed paper if it is extending into that area.
NOTE
If paper is loaded in the bypass tray, temporarily
remove the paper and close the bypass tray before
opening the side cover.
NOTE
The misfeed may have occurred inside the machine.
Check carefully and remove it.
