4-2
PART NAMES AND FUNCTIONS
(The Reversing Automatic Document Feeder)
Exterior
[ ]Original reminder (page 4-6)
Indicates an original is still on the document glass.
Document feeding area cover (page 7-2)
Open to remove misfed originals in this area.
Original guides (page 4-6)
Adjust to the size of the originals.
Document feeder tray (page 4-6)
Set the originals here for automatic feeding.
*RADF exit area cover (page 7-2)
Open to remove misfed originals.
*RADF exit area
Finished originals are output here.
Document cover
Document glass
All originals which cannot be copied from the
document feeder tray must be copied here.
* "RADF" is an acronym for "Reversing Automatic Document Feeder".
