PART NAMES AND FUNCTIONS

AUTOMATIC DOCUMENT FEEDER AND DOCUMENT

GLASS

(1) Paper feed roller

This roller rotates to automatically feed the original.

(2) Document feeding area cover

Open this cover to remove an original misfeed or clean

the paper feed roller.

(3) Original guides

These help ensure that the original is scanned correctly.

Adjust the guides to the width of the original.

(4) Document feeder tray

Place originals in this tray. 1-sided originals must be

placed face up.

(5) Original exit tray

Originals are delivered to this tray after scanning.

(6) Scanning area

Originals placed in the document feeder tray are scanned

here.

(7) Original size detector

This detects the size of an original placed on the

document glass.

(8) Document glass

Use this to scan a book or other thick original that cannot

be fed through the automatic document feeder.

(2)

(8)

(3) (4) (5) (6) (7)

(1)
