AR-651/810 TROUBLE SHOOTING 5 - 50

[EC0] Inserter feeding delay jam

Are the pickup roller, feed roller and separation roller tainted?

Clean up the rollers.

Is the harness between the inserter control board and separation sensor open-circuited?

Replace the harness.

Is the separation sensor working improperly?

Replace the separation sensor.

Replace the inserter control board.

[EC1] Inserter feeding stop jam

Are the transport roller and reverse roller tainted?

Clean up the rollers.

Is the harness between the inserter control board and separation sensor open-circuited?

Replace the harness.

Is the separation sensor working improperly?

Replace the separation sensor.

Replace the inserter control board.

NO

YES

NO

YES

NO

YES

NO

YES

NO

YES

NO

YES
