78
PERIPHERAL DEVICES AND SUPPLIES
REVERSING SINGLE PASS FEEDER
The reversing single pass feeder (RSPF) can automatically feed multi-page documents.
If the RSPF is installed, two-sided originals can be copied automatically without having to manually turn them over.
Part names
Specifications
STORAGE OF SUPPLIES
Standard supplies for this product that are to be replaced by the user are paper and the toner cartridge.
PROPER STORAGE
Store the supplies in a location that is:
• clean and dry,
• at a stable temperature,
• not exposed to direct sunlight.
Store paper in the wrapper and lying flat.
Paper stored out of the wrapper or in packages
standing on end may curl or get damp, resulting in
paper misfeeds.
AR-RP7
Acceptable originals
Weight
35 g/m
2
to 128 g/m
2
(9 lbs. to 34 lbs. )
(52 g/m
2
to 105 g/m
2
(14 lbs. to 28 lbs.) for two-sided original)
Size
A5 to A3 (5-1/2" x 8-1/2" to 11" x 17")
Capacity
Up to 100 sheets (Thickness 13 mm (33/64) and below)
Power supply
Drawn from the machine
Detectable original sizes
A5, A4, A4R, B4, A3
(5-1/2" x 8-1/2", 5-1/2" x 8-1/2"R, 8-1/2" x 11", 8-1/2" x 11"R, 8-1/2" x 14",
11" x 17")
Weight
Approx. 7.5 kg (16.6 lbs.)
Dimensions
586 mm (W) x 457 mm (D) x 145 mm (H)
(22-61/64" (W) x 17-9/64" (D) x 5-1/4" (H))
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification
changes for product improvement without prior notice. The performance specification figures indicated are
nominal values of production units and there may be some deviations from these values in individual units.
Exit area
Reversing tray
Document transport cover
Document transport cover knob
Original guides
Document feeder tray
Document feeder
cover
Note
For best copying results, be sure to use only SHARP products. Only genuine SHARP consumables carry the
Genuine Supplies label.
