BEFORE USING THE MACHINE
Contents
REPLACING THE STAMP CARTRIDGE
If a stamp unit (AR-SU1) is installed on the automatic document feeder and the stamp has become faint, replace the
stamp cartridge (AR-SV1).
Supplies
Stamp cartridge (2 in package) AR-SV1
1
Open the automatic document feeder.
2
Open the holders on the automatic
document feeder that hold the original
pressure sheet.
Open the holders (two) on the left and right sides.
3
Grasp the tab on the stamp unit and pull
the unit out.
4
Remove the stamp cartridge (A).
Tab
(A)
