2-70
COPIER
Contents
ADDING INSERTS WHEN COPYING ON
TRANSPARENCY FILM
(Transparency Inserts)
When copying on transparency film, the sheets may stick together due to static electricity. The transparency inserts
function can be used to automatically insert a sheet of paper between each sheet of transparency film, making the
sheets easy to handle.
It is also possible to copy on the inserts.
1
Place the transparency film in the
bypass tray.
• Transparency film can only be placed in the bypass tray.
• Place the transparency film face down on the bypass tray.
When placing the transparency film, the rounded corner of
the film should be:
- At the front and left if the film is oriented horizontally.
- At the back and left if the film is oriented vertically.
• After loading the transparency film, configure the bypass tray
settings as explained in "MAKING COPIES USING THE
BYPASS TRAY" (page 2-39).
2
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
3
Select the special modes.
(1) Touch the [Special Modes] key.
(2) Touch the [Transparency Inserts] key.
☞ Special modes menu (1st screen) (page 2-42)
C
B
A
Inserts
Oriented
horizontally
Oriented
vertically
