1-58
BEFORE USING THE MACHINE
Contents
5
Repeat step 4 with each of the other
main chargers.
There are a total of 4 places to be cleaned in the machine as
shown.
6
Replace the charger cleaner in its
original position.
7
Push the waste toner box into the
machine.
Push the waste toner box firmly in until it clicks into place.
8
Close the front cover.
• If this does not solve the problem, pull the knob out and push it back in 3 more times.
• When pulling and pushing the knob to clean the charger, pull and push the knob slowly from one end to the other.
Main charger
