37
Stapling positions and stapling results
Saddle stitch function
To select saddle stitch, touch the [Saddle Stitch] key in the output screen. If "Automatic Saddle Stitch" is enabled in the
system settings (administrator), the saddle stitch settings screen in the special modes will automatically appear.
For information on saddle stitch, see "MAKING COPIES IN PAMPHLET FORMAT (Pamphlet Copy)" (page 51).
Stapling positions
Stapling result
Vertically-oriented paper
Horizontally-oriented
paper
1 staple at top left corner
1 staple at bottom left corner
2 staples at left edge
Slant staple
Slant staple
Slanted stapling can be used when one staple at the top of the paper is selected
Saddle stitch
Result
Vertically-oriented paper Horizontally-oriented paper
