18
TURNING THE POWER ON AND OFF
The machine has two power switches. The main power switch is at the lower left after the front cover is opened. The
other power switch is the [POWER] key ( ) on the operation panel at the top right.
Main power switch
When the main power switch is switched on, the main
power indicator on the operation panel lights up.
[POWER] key
Turning on the power
(1) Switch the main power switch to the "on"
position.
(2) Hold down the [POWER] key ( ) until the
touch panel turns on.
The machine power turns on.
Turning off the power
(1) Hold down the [POWER] key ( ) until the
touch panel turns off.
(2) Switch the main power switch to the "off"
position.
Main power indicator
The main power indicator may light green or orange, depending on the machine's status.
"On" position
"Off" position
PROOF COPY
Main power indicator
[POWER] key
• Before turning off the main power switch, make sure that a job is not in progress or being processed.
Switching off the main power switch or removing the power cord from the outlet while a job is in progress or being
processed may damage the hard drive and cause data to be lost.
• Switch off both the [POWER] key ( ) and the main power switch and unplug the power cord if you suspect a machine
failure, if there is a bad thunderstorm nearby, or when you are moving the machine.
When using the fax or Internet fax function, always keep the main power switch in the "on" position.
What the main power indicator
indicates
Machine Configuration
Green The main power switch is turned on
Orange The fax or Internet fax function can be used on the machine and the power has been
turned off with the [POWER] key ( ) with the main power switch still switched on.
Off The main power switch is switched off
