PREPARATIONS FOR FAX
To use the machine as a fax, the telephone line must be connected and the type of line set.
Connection to the telephone line
Be sure to use the provided telephone line cord to connect the machine to the wall telephone jack. Connect the end of
the line cord that has the core to the "LINE" jack on the machine. Insert the other end (the end without the core) into a
telephone line jack.
Click!
Core
"LINE" jack
Insert the end of the cord with the
core into the "LINE" jack.
