CHAPTER 7. SERVICE PRECAUTION

1. Error code table

When the following error codes are displayed, press the key and take a proper action according to the table below.

Error

code

Error status Action

E01 Registration error Make a correct key entry.

E02 Misoperation error Make a correct key entry.

E03 Undefined code is entered. Enter a correct code, or declare it by the programming.

E04 Paper empty Replace a journal paper roll with a new one.

E05 Secret code error Enter a correct secret code.

E07 Memory is full. Expand the file within a capacity of memory.

E11 Compulsory depression of the

key for direct finalization Press the

key and continue the operation.

E12 Compulsory tendering Make a tendering operation.

E26 File type error Create files correctly.

E27 Power-off

E31 Compulsory non-add code entry Enter a non-add code.

E32 No entry of your cashier code Make a cashier code entry.

E33 The current cashier code should not be changed. Change a cashier after finalizing the transaction.

E34 Overflow limitation error Make a registration within a limit of entry.

E35 The open price entry is inhibited. Make a preset price entry.

E36 The preset price entry is inhibited. Make an open price entry.

E37 The direct finalization is inhibited. Make a tendering operation.

E39 Power-off during validation printing Print a validation again.

E67 Registration buffer is full.

E76 The drawer is still opened. Close the drawer.

E86 Communication error

E87 Data format error

E88 Time-out error

E94 Age verification error The dept./PLU is protected by the age limitation.

2. Conditions for soldering circuit parts

To solder the following parts manually, follow the conditions described below.

PARTS NAME PARTS CODE LOCATION CONDITIONS FOR SOLDERING

Front LED

(HDSP5621)

Front LED PWB: FND1-5 315°C/2 sec.

Pop-up LED

(HDSP-F501#S02)

Pop-up LED PWB: FND1-10 315°C/2 sec.

7 – 1
