1-17 Managing color on the Fiery
Sharp AR-C360P EFI Color Guide - 17
You can specify settings for the following options by selecting print
options when you send a job to the Fiery. Some can also be set as
defaults by the administrator during Fiery Setup or using Color-
Wise Pro Tools. Settings specified using print options override the
defaults.
Fiery color print option What it does
Brightness
85% Lightest to 115% Darkest
Performs a color adjustment on all color channels to make
the printed output lighter or darker.
CMYK Simulation Method
Quick/Full (Source GCR)/Full
(Output GCR)
(Default set at Setup or with
ColorWise Pro Tools)
Quick simulation applies one-dimensional transfer curves
that adjust output density only. The Full simulations apply
colorimetric transformations that adjust hue as well as
output density (see page 1-27).
CMYK Simulation Profile
SWOP-Coated (EFI)/DIC (EFI)/
Euroscale (EFI)/None
(Default set at Setup or in
ColorWise Pro Tools)
Adjusts CMYK color data to simulate an offset press
standard or a custom color gamut defined at your site.
Choosing None bypasses simulation (see page 1-26).
Color Mode (Mac OS)
CMYK/Grayscale
or
Print Mode (Windows)
Standard Color/Expert
Color/Grayscale
Specifies the output color space of the job. Select CMYK,
Standard Color, or Expert Color for a full-color document.
(Other) Gamma
1.0/1.2/1.4/1.6/1.8/2.0/2.2/2.4/2
.6/2.8/3.0
(Default set with ColorWise Pro
Tools)
Applies the specified gamma value to the RGB source space
definition (see page 1-25). To use this print option, you
must choose Other as the RGB Source Profile setting.
(Other) White Point
5000 K (D50)/5500 K/6500 K
(D65)/
7500 K/9300 K
(Default set with ColorWise Pro
Tools)
Applies the specified white point value to the RGB source
color space definition (see page 1-25). To use this print
option, you must choose Other as the RGB Source Profile
setting.
