2. Description of each section

(1) Paper feed section

Copying size A3 ∼ A6/Ledger ∼ Invoice

Paper feed system 1 tray + multi manual feed

Paper feed capacity 250 sheets × 1

Cassette Paper size Paper weight Paper kind

Tray

AB series: A3 ∼

56 ∼ 80g/m

Standard paper,

recycled paper

Inch series:

Ledger ∼ Invoice

15 ∼ 21 lbs

Multi

manual

paper

feed

Multi

AB series: A3 ∼

A6R

Inch series:

Ledger ∼ Invoice

56 ∼ 80g/m

Standard paper,

specified paper,

special paper,

OHP film, Second

original paper,

postcards

(without folding)

15 ∼ 21 lbs

Single

AB series: A3 ∼

A6R

Inch series:

Ledger ∼ Invoice

52 ∼

128g/m

14 ∼ 34 lbs

(2) Optical section

Light source Halogen lamp

Exposure system Slit exposure by moving the light source

Zooming system By changing the lens positions and the scan

speed.

Lens Fixed focus lens

(3) Process

Charging system (–) DC saw teeth electrode system

Transfer system (–) tungsten system

Separation system (AC) separation tungsten system

(4) Developing section

Developing system Dry, two-component magnetic brush

development (developer replacement)

Developing bias voltage DC–200V ±5V

(5) Fusing section

Fusing system Heat roller system

Upper heat roller surface temperature 190 degrees C

Heater lamp Halogen lamp 1000W × 1

3. Supply parts

Middle East/Africa

Name Content Life Product name

1 Photoconductor kit Photoconductor drum x 1

Cleaner blade x 1

Drum separation pawl x 2

60K SF-226DM

2 Black developer Black developer (530g) x 10 60K x 10 SF-226LD

3 Black toner Black toner bottle (280g) x 10 6K x 10 SF-126LT

4 Upper heat roller kit Upper heat roller x 1

Upper separation pawl x 4

Fusing bearing x 1

120K SF-216HU

5 Lower heat roller kit Lower heat roller x 1

Lower separation pawl x 4

120K SF-220LH

6 Staple cartridge Staple cartridge (For SF-S54) x 3 5K staples x 3 SF-LS12

7 Upper heat roller Upper heat roller x 1 120K SF-216HU

8 Upper separation pawl Upper separation pawl x 4 x 10 120K x 10 SF-216UP

9 Heat roller gear Heat roller gear x 10 120K x 10 SF-216HG

10 Lower heat roller Lower heat roller x 1 120K SF-216HR

11 Lower separation pawl Lower separation pawl x 4 x 10 120K x 10 SF-216LP

12 Screen grid Screen grid x 10 120K x 10 SF-216SU

13 Cleaner blade Cleaner blade x 10 6K x 10 SF-216CB

14 Charging plate Charging plate x 10 120K x 10 SF-216PU

15 Ozone filter Ozone filter x 10 300K x 10 SF-216FL

16 Copy lamp Copy lamp x 10 — SF-216CL

17 MC case unit MC case unit x 10 — SF-216MC

2 – 2
