F. Comparison table of lens values and simulation input values
Lens
display
value
Sim 48-01
Zoom correction
(Enlargement)
Zoom correction
(Reduction)
Sim 48-01 — % Sim 48-01 — %
—
%
+4.0 30 70 70
+3.9 31 69 69
+3.8 31 69 69
+3.7 32 68 68
+3.6 32 68 68
+3.5 33 67 67
+3.4 33 67 67
+3.3 34 66 66
+3.2 34 66 66
+3.1 35 65 65
+3.0 35 65 65
+2.9 36 64 64
+2.8 36 64 64
+2.7 37 63 63
+2.6 37 63 63
+2.5 38 62 62
+2.4 38 62 62
+2.3 39 61 61
+2.2 39 61 61
+2.1 40 60 60
+2.0 40 60 60
+1.9 41 59 59
+1.8 41 59 59
+1.7 42 58 58
+1.6 42 58 58
+1.5 43 57 57
+1.4 43 57 57
+1.3 44 56 56
+1.2 44 56 56
+1.1 45 55 55
+1.0 45 55 55
+0.9 46 54 54
+0.8 46 54 54
+0.7 47 53 53
+0.6 47 53 53
+0.5 43 52 52
+0.4 48 52 52
+0.3 49 51 51
+0.2 49 51 51
+0.1 50 50 50
050 50 50
–0.1 50 50 50
–0.2 51 49 49
–0.3 51 49 49
–0.4 52 48 48
–0.5 52 48 48
–0.6 53 47 47
–0.7 53 47 47
Lens
display
value
Sim 48-01
Zoom correction
(Enlargement)
Zoom correction
(Reduction)
Sim 48-01 — % Sim 48-01 — %
—
%
–0.8 54 46 46
–0.9 54 46 46
–1.0 55 45 45
–1.1 55 45 45
–1.2 56 44 44
–1.3 56 44 44
–1.4 57 43 43
–1.5 57 43 43
–1.6 58 42 42
–1.7 58 42 42
–1.8 59 41 41
–1.9 59 41 41
–2.0 60 40 40
–2.1 60 40 40
–2.2 61 39 39
–2.3 61 39 39
–2.4 62 38 38
–2.5 62 38 38
–2.6 63 37 37
–2.7 63 37 37
–2.8 64 36 36
–2.9 64 36 36
–3.0 65 35 35
–3.1 65 35 35
–3.2 66 34 34
–3.3 66 34 34
–3.4 67 33 33
–3.5 67 33 33
–3.6 68 32 32
–3.7 68 32 32
–3.8 69 31 31
–3.9 69 31 31
–4.0 70 30 30
7 – 9
