Middle & South America/Asia (excluding China)

Name Content Life Product name

1 Photoconductor kit Photoconductor drum x 1

Cleaner blade x 1

Drum separation pawl x 2

60K SF-226DR

2 Black developer Black developer (530g) x 10 60K x 10 SF-226CD

3 Black toner Black toner bottle (280g) x 10 6K x 10 SF-126CT

4 Upper heat roller kit Upper heat roller x 1

Upper separation pawl x 4

Fusing bearing x 1

120K SF-216HU

5 Lower heat roller kit Lower heat roller x 1

Lower separation pawl x 4

120K SF-220LH

6 Staple cartridge Staple cartridge (For SF-S54) x 3 5K staples x 3 SF-LS12

7 Upper heat roller Upper heat roller x 1 120K SF-216HU

8 Upper separation pawl Upper separation pawl x 4 x 10 120K x 10 SF-216UP

9 Heat roller gear Heat roller gear x 10 120K x 10 SF-216HG

10 Lower heat roller Lower heat roller x 1 120K SF-216HR

11 Lower separation pawl Lower separation pawl x 4 x 10 120K x 10 SF-216LP

12 Screen grid Screen grid x 10 120K x 10 SF-216SU

13 Cleaner blade Cleaner blade x 10 6K x 10 SF-216CB

14 Charging plate Charging plate x 10 120K x 10 SF-216PU

15 Ozone filter Ozone filter x 10 300K x 10 SF-216FL

16 Copy lamp Copy lamp x 10 — SF-216CL

17 MC case unit MC case unit x 10 — SF-216MC

2 – 3
