7-18
CHAPTER7
OPTIONAL EQUIPMENT
Finisher (AR-FN3)
FINISHER (AR-FN3)
●
If the misfed paper is not seen in the paper transport area, turn
the roller rotating knob to feed the paper.
6
Close the paper transport area cover.
●
Confirm that the misfeed display is cleared.
Roller rotating knob
