8-1
CHAPTER8
CHAPTER 8
KEY OPERATOR’S GUIDE
This chapter contains information on all of the programs for use by the
key operator. The programs allow the key operator to tailor many
functions of the AR-507 for specific modes of operation. These
programs can only be accessed after a key operator code number has
been entered.
Please familiarise yourself with this chapter and refer to it for the
information you need to keep the copier operating smoothly.
Page
●●
●●
●
KEY OPERATOR CODE NUMBER ..................... 8-2
Registering the key operator code number ................ 8-2
●●
●●
●
KEY OPERATOR PROGRAMS ........................ 8-4
Using the key operator programs ....................... 8-7
●●
●●
●
KEY OPERATOR ASSISTANCE CALL ................. 8-31
●●
●●
●
KEY OPERATOR CODE NUMBER:
FACTORY SETTING ............................... 8-33
