3-17
CHAPTER3
SPECIAL FUNCTIONS Pamphlet copy
PAMPHLET COPY
Originals
(2-sided)
Originals
(1-sided)
READY TO CO
The PAMPHLET COPY function is used to arrange copies in proper
order for eventual centre-stapling and folding into a booklet. Four
pages will be copied onto one sheet.
●
Centre stapling cannot be performed by this copier.
Even if PAMPHLET COPY is selected and an optional finisher
(AR-FN3) is installed, centre-stapling cannot be performed.
●
This function will not work when non-standard size originals or copy
paper are used.
1
Place the originals in the document feeder tray or on the
document glass.
●
When using the document glass, place the originals one at a time
starting with the first original .
2
Press the SPECIAL MODES key.
●
The SPECIAL MODES screen will appear.
