ADJ M17 Image quality adjustment

START

Perform ADJ1 CCD gamma

adjustment.

Copy color balance density check

(Check in the TEXT/Photo mode.)

(Test chart UKOG-0162FCZZ/

UKOG-0283FCZZ is used.)

Is the

copy color balance/

density adjustment

required ?

Perform ADJ2 copy color balance/density auto

adjustment. (SIM 46-24)

YES

NO

In the fine

adjustment, the copy

color balance and the density

are in the standard

level.

Is the color balance/

density adjustment

performed for each copy mode ? (Does

the user request that ?)

Was CCD replaced ?

YES

YES

YES

NO

NO

NO

Perform the manual adjustment of

ADJ3 copy color balance, density

adjustment. (SIM 46-21)

Perform the copy density

adjustment in the low

density section for ADJ4

each the copy modes.

(SIM 46-1/2)

Is the copy density

adjustment in the low density section

performed for all the copy modes ?

(Does the user request

for it ?)

Are the copy color balance and

the density in the specified level ?

YES

YES

NO

NO

Perform the copy density

adjustment in the low

density section for ADJ4

all the copy modes.

(SIM 46-10 – 19)

Check the copy color balance and the

density. (Check in the Text/Photo mode.)

(Use the test chart UKOG-0283FCZZ.)

END

Set the SIT chart

(UKOG-0280FCZZ) on

the original table.

Enter the SIM 63-03

mode and press the

EXECUTE key.

Enter the SIM 46-24 mode and select

C:A3 (11 17) paper. (Auto selection)

Press the EXECUTE key. (The

adjustment pattern 1 is printed.)

Set the adjustment pattern 1 on the

original table, select the SERVICE

mode, and press the EXECUTE key.

(Auto adjustment step 1)

Press the REPEAT key.

Press the EXECUTE key.

(Adjustment pattern 2 is printed.)

Set the adjustment pattern 2 on the

original table, and press

the EXECUTE key.

(Auto adjustment step 2)

Press the OK key. (The initial setup

of half tone image correction is

automatically performed.)

Are the color

balance and the density

in the specified level ?

YES

NO

Cancel SIM 46-24.

SET M1 Auto color balance adjustment target is set.

(SIM 63-7)

Enter the SIM 63-7 mode.

Press the SETUP key.

Set the color patch image (adjustment

pattern) printed in the copy color balance/

density adjustment on the original table, and

press the EXECUTE key.

Press the REPEAT key.

Press the EXECUTE key.

Press the OK key.

Cancel SIM 63-7.

Perform the initial setup of half tone image

correction. (SIM 44-21)

Execute the half tone image correction.

(Forcible execution) (SIM 44-26)

AR-C150

7 – 21
