AR-BC320 TROUBLESHOOTING 11 - 20

H4 00 Case 2 Cause The heater lamp keeps ON

with SIM 5-2. Heater lamp

trouble, thermostat trouble,

interlock switch trouble, AC

power supply trouble, PCU

PWB (lamp control circuit)

trouble

Check &

Remedy

Check for disconnection of

the heater lamp and the

thermostat. Check the

interlock switch. Check the

AC PWB and the PUC

PWB lamp control circuit.

Cancel the error with SIM

14.

Main

code

Sub

code

Title

Fusing section low temperature

trouble (HL2)

H4 01 Display Lamp/Message

Phenomenon Detail The fusing temperature is

not reached within the

specified time after turning

on the power relay.

Section Fusing

Common Check Use SIM 5-2 to check the

heater lamp flashing

operation.

Case 1 Cause The heater lamp flashes

properly with SIM 5-2.

Thermistor trouble, PCU

PWB (thermistor input

circuit) trouble

Check &

Remedy

Check the thermistor and

its harness. Check the

PCU PWB thermistor input

circuit.

Cancel the error with SIM

14.

Case 2 Cause The heater lamp keeps ON

with SIM 5-2.

Heater lamp trouble,

thermostat trouble,

interlock switch trouble, AC

power supply trouble, PCU

PWB (lamp control circuit)

trouble

Check &

Remedy

Check for disconnection of

the heater lamp and the

thermostat. Check the

interlock switch. Check the

AC PWB and the PUC

PWB lamp control circuit.

Cancel the error with SIM

14.

Main

code

Sub

code

Title

Fusing section low temperature

trouble (HL1)

Main

code

Sub

code

Title

Five continuous detections of

POD1 not-reached jam

H5 01 Display Lamp/Message

Phenomenon Detail POD1 not-reached jams

are detected for five times

continuously.

Section Fusing

Case 1 Cause A fusing jam is not

canceled completely. (Jam

paper remains inside the

machine.)

Check &

Remedy

Check remaining jam

paper (winding).

Cancel the error with SIM

14.

Case 2 Cause POD1 sensor trouble, or

harness disconnection

Check &

Remedy

Check POD1 sensor

harness.

Cancel the error with SIM

14.

Case 3 Cause Improper installation of the

fusing unit

Check &

Remedy

Check installation of the

fusing unit.

Cancel the error with SIM

14.

Main

code

Sub

code

Title

Mirror feed trouble

L1 00 Display Lamp/Message

Phenomenon Detail Mirror feed is not

completed within the

specified time.

Section —

Case 1 Cause Mirror unit trouble, mirror

wire breakage

Check &

Remedy

Use SIM 1-1 to check the

mirror operation.

Main

code

Sub

code

Title

Mirror return trouble

L3 00 Display Lamp/Message

Phenomenon Detail Mirror return is not

completed within the

specified time.

Section —

Case 1 Cause Mirror unit trouble, mirror

wire breakage

Check &

Remedy

Use SIM 1-1 to check the

mirror operation.
