AR-BC320 TROUBLESHOOTING 11 - 9

Main

code

Sub

code

Title

Finisher punch motor trouble

F1 34 Display Lamp/Message

Phenomenon Detail Punch motor operation

trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher punch side registration

sensor trouble

F1 35 Display Lamp/Message

Phenomenon Detail Sensor input value

abnormality

Section Finisher

Case 1 Cause Sensor breakage

Check &

Remedy

Use SIM 3-2 to check the

sensor operation.

Case 2 Cause Harness disconnection

Check &

Remedy

Same as case 1.

Case 3 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher punch registration

sensor trouble

F1 36 Display Lamp/Message

Phenomenon Detail Sensor input value

abnormality

Section Finisher

Case 1 Cause Sensor breakage

Check &

Remedy

Use SIM 3-2 to check the

sensor operation.

Case 2 Cause Harness disconnection

Check &

Remedy

Same as case 1.

Case 3 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher backup RAM trouble

F1 37 Display Lamp/Message

Phenomenon Detail Writing to the backup RAM

is started but not

completed in 250msec.

When writing to the backup

RAM, if the write data do

not coincide with the read

data, writing is performed

again. However, the write

data still do not coincide

with the read data.

Section Finisher

Case 1 Cause Console finisher control

PWB, backup RAM trouble

Check &

Remedy

Replace the console

finisher control PWB.

Case 2 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Case 3 Cause Malfunction caused by

noises

Check &

Remedy

Turn off the machine

power, and turn it on again.

Main

code

Sub

code

Title

Finisher punch backup RAM

trouble

F1 38 Display Lamp/Message

Phenomenon Detail Abnormal transformation

of punch unit backup RAM

contents

Section Finisher

Case 1 Cause Punch control PWB trouble

Check &

Remedy

Replace the punch control

PWB.

Case 2 Cause Malfunction caused by

noises

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher punch dust sensor

trouble

F1 39 Display Lamp/Message

Phenomenon Detail Punch dust sensor

detection trouble

Section Finisher

Case 1 Cause Sensor breakage

Check &

Remedy

Use SIM 3-2 to check the

sensor operation.

Case 2 Cause Harness disconnection

Check &

Remedy

Same as Case 1.

Case 3 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.
