NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
FO-4970U
– 26 –
[16] Power Supply PWB Unit
28 QPLGZ0347PAZZ AF C Connector(12pin) [CN5]
29 QSOCA0030PAZZ AG C AC socket [CNAC]
30 VHD1SS244//-1 AC B Diode(1SS244) [D1]
31 VHDFMXG12S/-1 AG B Diode(FMXG12S) [D2]
32 VHDFMB-24M/-1 AF B Diode(FMB-24M) [D3]
33 VHDERA2206/-1 AD B Diode(ERA22-06) [D4]
34 VHD1SS270A/-1 AA B Diode(1SS270A) [D5]
35 VHDD3SBA60/-1 AG B Diode(D3SBA60) [DB2]
36 QFS-F0046PAZZ AD A Fuse(125V 4A) [FS1]
37 QFSHA0016PAZZ AC C Fuse-holder [FS1]
38 QFS-F0020PAZZ AD A Fuse(125V 8A) [FS2]
39 QFSHA0016PAZZ AC C Fuse-holder [FS2]
40 QFS-F0046PAZZ AD A Fuse(125V 4A) [FS3]
41 QFSHA0016PAZZ AC C Fuse-holder [FS3]
42 QFS-F0046PAZZ AD A Fuse(125V 4A) [FS4]
43 QFSHA0016PAZZ AC C Fuse-holder [FS4]
44 RH-IX0783PAZZ AD B IC(L5431) [IC1]
45 RH-IX1659PAZZ AP B IC(PQ30RV21) [IC2]
46 RTRNZ0577PACT AK C Line-Filter [L1]
47 VHVC271D10A-1 AD B Varistor(ENC271D-10A) [NR1]
48 VHVC271D10A-1 AD B Varistor(ENC271D-10A) [NR2]
49 VHVC271D10A-1 AD B Varistor(ENC271D-10A) [NR3]
50 QSPGH0007PAZZ AK C Varistor(DSA302A) [NR4]
51 RH-PX0296PAZZ AF B Photo coupler(PC817X2) [PC1]
52 VHRS21MT2//-1 AK B Photo coupler(S21MT2) [PC2]
53 VS2SC1213-C1A AC B Transistor(2SC1213C) [Q2]
54 VSDTC114ESA-1 AC B Transistor(DTC114ESA) [Q3]
55 VSDTA114ESA-1 AC B Transistor(DTA114ESA) [Q4]
56 VS2SK2185//-1 AL B Transistor(2SK2185) [Q10]
57 VRD-ST2CD474J AA C Resistor(1/6W 470KΩ ±5%) [R1]
58 VRD-ST2CD274J AB C Resistor(1/6W 270KΩ ±5%) [R4]
59 VRD-ST2CD274J AB C Resistor(1/6W 270KΩ ±5%) [R5]
60 VRS-FT3DD220J AC C Resistor(2W 22Ω ±5%) [R6]
61 VRD-ST2HF681J AB C Resistor(1/2W 680Ω ±5%) [R8]
62 RR-NZ0065PAZZ AB C Resistor(1/4W 3.9KΩ) [R9]
63 VRD-ST2CD223J AA C Resistor(1/6W 22KΩ ±5%) [R10]
64 VRD-ST2CD473J AA C Resistor(1/6W 47KΩ ±5%) [R11]
65 RR-XZ0065PAZZ AC C Fusing resistor(1/6W 2.2Ω) [R12]
66 VRD-ST2CD122J AA C Resistor(1/6W 1.2KΩ ±5%) [R13]
67 VRD-ST2CD331J AA C Resistor(1/6W 330Ω ±5%) [R14]
68 VRD-ST2CD473J AA C Resistor(1/6W 47KΩ ±5%) [R15]
69 VRD-ST2CD222J AA C Resistor(1/6W 2.2KΩ ±5%) [R16]
70 VRD-ST2CD223J AA C Resistor(1/6W 22KΩ ±5%) [R18]
71 RR-SZ0074PAZZ AB C Resistor(2W 1KΩ) [R19]
72 RR-SZ0074PAZZ AB C Resistor(2W 1KΩ) [R20]
73 VRD-ST2HF122J AA C Resistor(1/2W 1.2KΩ ±5%) [R21]
74 VRD-ST2HF101J AA C Resistor(1/2W 100Ω ±5%) [R22]
75 VRD-ST2HF104J AA C Resistor(1/2W 100KΩ ±5%) [R24]
76 VRD-ST2CD183J AA C Resistor(1/6W 18KΩ ±5%) [R25]
77 VRD-ST2CD222J AA C Resistor(1/6W 2.2KΩ ±5%) [R26]
78 VRD-ST2CD222J AA C Resistor(1/6W 2.2KΩ ±5%) [R27]
79 VRD-ST2CD222J AA C Resistor(1/6W 2.2KΩ ±5%) [R28]
80 VRD-ST2CD330J AA C Resistor(1/6W 33Ω ±5%) [R29]
81 VRD-ST2CD330J AA C Resistor(1/6W 33Ω ±5%) [R30]
82 RR-XZ0078PAZZ AC C Fusing resistor(1/6W 33Ω) [R35]
83 RR-XZ0076PAZZ AC C Fusing resistor(1/6W 15Ω) [R41]
84 RR-SN2322PA6F AB C Resistor(1/6W 23.2KΩ) [R51]
85 RR-NZ0064PAZZ AB C Resistor(1/4W 1.2KΩ) [R52]
86 VRD-ST2CD124J AB C Resistor(1/6W 120KΩ ±5%) [R62]
87 RRLYZ0101PAZZ AK B Relay(SDT-SS-124DM) [RL1]
88 VHSTF321S//-1 AG B Thyristor(TF321S) [SCR1]
89 VHS03P2M///-3 AG B Thyristor(03P2M(L)) [SCR2]
90 QSW-C0048PAZZ AN C Switch(AJ7220BK) [SW1]
91 RTRNZ0674PACD AQ B Trans former [T1]
92 VHH11D8R0LA-1 AF B Thermistor(NTH11D8R0LA) [TH1]
93 VHSTM1241I/-1 AN B Thyristor(TM1241I) [TRC1]
94 RVR-M0390PAZZ AD C Variable resistor [VR1]
95 VHEHZS6B2//-1 AC B Zener diode(HZS6B2) [ZD1]
96 VHEHZS15-3/-1 AC B Zener diode(HZS15-3) [ZD2]
97 VHEHZS6B2//-1 AC B Zener diode(HZS6B2) [ZD3]
98 VHEHZS27-3/-1 AC B Zener diode(HZS27-3) [ZD4]
99 VHEHZS36-1/-1 AC B Zener diode(HZS36-1) [ZD5]
100 QLUGZ0008PAZZ AC C SW LUG
B1 LX-BZ0241PAZZ AA C Screw(3x8)
B2 LX-BZ0254PAZZ AB C Screw(3x6)
B3 LX-BZ0273PAZZ AB C Screw(3x6)
B4 LX-BZ0427PAZZ AB C Screw(3x14)
B5 XBSSN30P06000 AA C Screw(3x6)
(Unit)
!
901 RDENT2135XHZZ BM E Power supply PWB unit
