Specifications

BVM-E250A BVM-E170A

Picture Performance

Panel OLED panel

Picture size (diagonal) 623.4 mm (24 5/8 inches) 419.7 mm (16 1/2 inches)

Effective picture size (H x V) 543.4 x 305.6 mm (21 1/2 x 12 1/8 inches) 365.8 x 205.7 mm (14 1/2 x 8 1/8 inches)

Resolution (H x V) 1920 x 1080 pixels (Full HD)

Aspect 16:9

Pixel efficiency 99.99%

Panel drive RGB 10-bit

Panel frame rate 48 Hz / 50 Hz / 60 Hz / 72 Hz / 75 Hz

(48 Hz, 60 Hz, and 72 Hz are also compatible with 1/1.001 frame rates)

Viewing angle (panel specification) 89°/89°/89°/89° (typical) (up/down/left/right contrast > 10:1)

Color temperature D55, D61, D65, D93, D-Cine, and user

Standard luminance 100 cd/m

(preset1 to preset5)

48 cd/m

(preset (D-Cine))

(100% white signal input)

Color space (color gamut) ITU-R BT.709, EBU, SMPTE-C, D-Cine*

, E250A / E170A Native*

, S-GAMUT*

The BVM-E250A / BVM-E170A individual chromaticity points: R (x = 0.681, y = 0.319) / G (x = 0.189, y = 0.724) / B (x= 0.141, y= 0.051) (typical)

Input

SDI BNC (x2)

HDMI HDMI (x1) (HDCP correspondence, Deep Color correspondence)

DisplayPort DisplayPort connector (x1)

Option port 4 ports

Parallel remote D-sub 9-pin (female) (x1)

Serial remote (LAN) Ethernet (10BASE-T/100BASE-TX), RJ-45 (x1)

Output

SDI BNC (x1)

DC 5 V out Circle 4-pin (female) (x1)

General

Power requirement

AC 100 V to 240 V, 1.6 A to 0.8 A, 50/60 Hz

AC 100 V to 240 V, 1.2 A to 0.7 A, 50/60 Hz

DC 24 V to 28 V, 4.5 A to 3.9 A

Power consumption Approx. 145 W (max.)

Approx. 72 W

(average power consumption in the default status)

Approx. 110 W (AC), 100 W (DC) (max.)

Approx. 60 W (AC), 60 W (DC)

(average power consumption in the default status)

Operating temperature 0°C to 35°C (32°F to 95°F)

Recommended: 20°C to 30°C (68°F to 86°F)

Operating humidity 0% to 90% (no condensation)

Storage and transport temperature -20°C to +60°C (-4°F to +140°F)

Storage and transport humidity 0% to 90%

Operating, storage, and transport pressure 700 hPa to 1060 hPa

Dimensions (W x H x D) 576.0 x 424.0 x 148.0 mm

(22 3/4 x 16 3/4 x 5 7/8 inches)

436.0 x 282.4 (266.4)*

x 214.7 mm

(17 1/4 x 11 1/4 (10 1/2)*

x 8 1/2 inches)

Mass 13.0 kg (28 lb 11 oz) 8.6 kg (18 lb 15 oz)

Supplied accessories

AC power cord (1), AC plug holder (1), Bracket (1), Operation Manual (Japanese,

English, each 1), CD-ROM (1), Using the CD-ROM Manual (1)

AC power cord (1), AC plug holder (1), Rack mount bracket (left, right, each 1), Rack

mount attachment screws (4), Operation Manual (Japanese, English, each 1),

CD-ROM (1), Using the CD-ROM Manual (1)

*1 Chromaticity point of SMPTE RP431-2 is not covered in full.

*2 The widest color space setting of the signal reproduced by the BVM-E250A and BVM-E170A.

*3 S-GAMUT is available for displaying the color gamut of the wide color space mode S-GAMUT, which is offered with the F23 and F35 Digital cinematography cameras.

*4 Height without monitor feet.
