IBX-530B-270 Embedded System

Page 31

4.2.2 Unpacking

After the IBX-530B-N270 is received make sure the following components are included in

the package. If any of these components are missing, please contact the IBX-530B-N270

reseller or vendor where it was purchased or contact an IEI sales representative

immediately.

Quantity Item Image

IBX-530B-N270 embedded system

36 W 12 V power adaptor with ERP and PSE

certificates

Power cord

Screw set

Foot pads

Wall mount kit

Driver and manual CD

Wireless antenna (optional)

DIN mount kit (optional)
