50
REPLACING SUPPLIES AND MAINTENANCE
Cleaning the PT charger of the primary transfer belt unit
If black or colored lines still remain after the document glass / automatic
document feeder and main charger have been cleaned, use the PT charger
cleaner to clean the PT charger.
1
Press the [POWER] key ( ) on the operation panel
to turn off the panel power, and then switch the
main power switch to the off position.
2
Open the front cover and remove the toner
collection container.
☞ Replacing the toner collection container (page 15)
mxc401_us_saf.book 50 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
